| MODEL |
LENGTH |
DIAMETER |
APPROVAL |
| YN25-700 |
28" (700MM) |
25 MM |
UL |
| YN25-1000 |
40" (1000MM) |
25 MM |
UL |
| YN25-1200 |
47" (1200MM) |
25 MM |
UL |
| YN25-1500 |
59" (1500MM) |
25 MM |
UL |
| YN25-1800 |
71" (1800MM) |
25 MM |
UL |
| YB25-700FM |
28" (700MM) |
25 MM |
UL/FM |
| YB25-1000FM |
40" (1000MM) |
25 MM |
UL/FM |
| YB25-1200FM |
47" (1200MM) |
25 MM |
UL/FM |
| YB25-1500FM |
59" (1500MM) |
25 MM |
UL/FM |
| YB25-1800FM |
71" (1800MM) |
25 MM |
UL/FM |
| * |
YN25 MODEL : NON BRIADED STAINLESS STEEL CORRUGATED HOSE |
| * |
YB25 MODEL : STAINLESS STEEL BRAIDED HOSE |
| * |
FLEXDROP WITH LENGTHS MORE THAN 71 INCH (1800 MM ) UP TO 100 INCH (2575 MM) IS AVAILABLE FOR SPECIAL ORDER ONLY ( FM APPROVAL ONLY FOR HOSES LONGER THAN 6 FOOT) |
| * |
FLEXDROP WITH 28 MM DIAMETER IS AVAILABLE FOR SPECIAL ORDER ONLY. OUR 28 MM DIAMETER FLEX DROP HAS THE BEST FRICTION LOSS VALUE. PLESE REFER FRICTION LOSS TABLE. |
 |
| Inlet Connection |
DN25, Male BSP or NPT thread |
| Outlet Connection |
1/2" or 3/4" Female NPT thread |
| Internal Diameter |
25mm or 28mm |
| Hose Length |
700mm(28"), 1000mm(40"), 1200mm(47"), 1500mm(59"), 1800mm(71") and Other lengths on request. |
| Bar Length |
700mm(28"), 1000mm(40"). Other lengths are available. |
| Working Pressure |
200 psi (13 bar) |
|
|
|
